PROFESSIONAL DISHWASHER

DWCBI231.W/1

This built-in stainless steel dishwasher for professional use with two flexible baskets can hold up to 13 place settings. 10 programs and a low noise level (46 dBA) make it easy to find the right setting for sparkling clean dishes, every time – and at any time. Turbo Drying™ ensures that the dishes are dry and cool when the machine has finished the programme

Energy Rating: A++

Get In Touch

PROFESSIONAL DISHWASHER

DWCBI231.W/1

This built-in stainless steel dishwasher for professional use with two flexible baskets can hold up to 13 place settings. 10 programs and a low noise level (46 dBA) make it easy to find the right setting for sparkling clean dishes, every time – and at any time. Turbo Drying™ ensures that the dishes are dry and cool when the machine has finished the programme

Energy Rating: A++

Get In Touch

Specifications

Construction

Installation Type	For installation under table top
External Drum	Stainless steel
Adjustable base	Vertical
Front adjustable rear foot	Yes
Size	XL, 820mm
Number of baskets	2

Standard Electrical Connection

Frequency	50 Hz
Connection Effect	1900w
Fuse	10
Volts (V)	220 – 240V
Heat Effect	1800W
Number of Phases	1
Wire Length	1825mm

Water & Sewer Connection

Water connection	Hot & Cold
Required pressure in water supply	0.03-1
Descaling agent	Yes
Type of protection against water damage	Anti Block – Self cleaning pump that protects against waste. Light and sounds alarm Maximum time for water intake Durable PEX inlet hose Protection against leakage when the machine is switched off Aqua Level sensor – the sensor in the machine registers whether the amaount of water matches the program that has been selected. Aqua Detect – detects when the water level is too high indentifies water leakage on the base plate Waterproof base plate Welded steel vessel Aqua Safe System – Protects against water damage
Length, intake hose	163cm
Length, outlet hose	200cm
Max. incoming water temperature	70’c

Steering

Control Type	With buttons
Delayed Start	Ne delay options
Possibility to create your own programs	No
Digital countdown indicator	Yes, On Screen
Language	Chinese simplified Chinese traditional Swedish Slovenian Russian Portuguese Polish Norwegian German Latvian Lithuanian Japanese Italian Croatian French Finnish Estonian Spanish English Danish

Drying Unit

Concealed heating element	Yes
Drying system	Turbo Drying ensures that the dishes are dry and cooled with fan-assisted removal of steam

Logistic information

Product width	595mm
Product hieght	819mm
Product depth	559mm
Product width (packed)	640mm
Product hieght (packed)	890mm
Product depth (packed)	680mm
Minimum niche height	820mm
Minimum niche width	600mm
Minimum niech depth (including extra distance to wall)	560mm
Net weight	41kg
Gross wieght	44.3kg
Adjustable height	50mm
Adjustable base	30-94/0
Max. product height	869mm
Depth with door open	1198mm

Characteristics

Number of programs	9
Number of different wash tempertures	6
Single basket washing	Not possible
Indicator at end	Indicated with sound anf light
Low salt indicator	Warning appears in display
Indication of low level of rainse aid	Warning appears in display
Interior lighting	Yes, 2 LED lights
Simple installation	Anti Siphon device – prevents spontaneous inflow and outflow of water, and simplifies elevated installation Stripe that protects againsst steam
Protects against water damage	Yes
Child lock	No
Upper basket consits of	Dense thread pattern in upper basket Handle Handle with ASKO logo Fold down wine glass holder on both sides Fixed plate row Fixed glass holder Standard knife holder Easy- glide telescopic rails with ball bearings
Middle basket	Without middle basket
Bottom basket	Dense wire pattern in basket, ensures that small objects do not fall through Handle Handle with ASKO logo Fold down rear row for pegs Cutlery basket

Performance

Shortage program time	Quick 20 mintue
Space for the number of encelopes	13
Number of water jet levels	2
Washing ability	A
Drying ability	A
Main components	Vitial parts of the dishwasher are made of stainless steel
Water concumption per wash with the eco programme	9.9L
Sound level (max) dB(A)	46
Final rinse temperature for 3 mintues	80’c

Energy Level

Energy Class	A++
Energy comsumption in standby	0.49w
Energy comsumption per cycle	0.92 kWh
Duration of standard programme	230min
Airborne acoustic noise emission	C
EEE	54.9
Drying performance	1.07
Cleaning performance index	1.13
Weighted energy use/ 100 cycles	92 kWh

Programmes

Program

SANI Quick

SANI

Self-cleaning

Crystal glass

Universal

Rinse and hold

Eco

Intensive

Quick Wash

Type of upper basket

Premium – Flexible basket in stable steel construction, easy to fill, with easy to glide telescopic rails

Bottom of bottom basket

Steel wire basket, fixed plate rows and removable cutlery basket

Functions

8 steel + acid-proof container

There are not many structures that are as stable as steel structures. In ASKO professional dishwasher, eight of the most important components are made of quality stainless steel: the container, the loading rails, the spray pipe, the spray arms, the external plinth, the feet, the stainer and the heating element. In addition, ASKO professional dishwashers are equipped with an extra durable and acid proof container and door made of extra good quality steel.
